14.BCD DATA OUTPUT(OPTION)

95

STROBE

Strobe pulses are outputted in synchronization with BCD data. Read data using the rising

edges of the pulses. The BCD data update rate setting can be changed.

14-6. BCD Data Update Rate Selection

Output rate: 1, 10, 100, 1000 times

How to set

14-7. BCD Output Data Selection

Output data: Hold values, Real-time values

How to set

BCDdata

OVER

Storobe range

STROBE

0

1

Setting call

Page 1

Option

Setting call

Page 1

Option
