GDM-8200A Series User Manual
96
Configure Interface
Overview
Interface type USB Device USB 1.1 or 2.0, TypeA, female
connector.
RS-232C D-sub 9 pin, male connector. Baud
rate: 115200/57600/38400/19200/
9600.
Return to Local
control mode In order to switch back to the
Local control mode (front panel
operation), press the LOCAL key.
Configure USB interface
USB device port
configuration
1. Press the Shift key, the 2ND
(Menu) key, the Right key
twice. The I/O configuration
menu appears.
2. Press the Down key. The USB
selection display appears.
3. Press the Down key. The USB
ON/OFF selection appears.
4. Press the Up/Down key to
select ON or OFF.
