GDM-8200A Series User Manual
118
2W Resistance
Note

Max. Input: 500V DC or 500V rms AC

*: Relative mode

When measuring resistances higher than 500kΩ, please
use shielded test cables to reduce noise interference.
Rate Range
Full Scale
(GDM-8251A) Full Scale
(GDM-8255A) Accuracy
reading%+digits
S
100.000Ω 120.000Ω 199.999Ω 0.1% + 8*
1.00000kΩ 1.20000kΩ 1.99999kΩ 0.08% + 5*
10.0000kΩ 12.0000kΩ 19.9999kΩ 0.06% + 5*
100.000kΩ 120.000kΩ 199.999kΩ 0.06% + 5
1.00000MΩ 1.20000MΩ 1.99999MΩ 0.06% + 5
10.0000MΩ 12.0000MΩ 19.9999MΩ 0.3% + 5
100.000MΩ 120.000MΩ 199.999MΩ 3.0% + 8
M
100.00Ω 120.00Ω 199.99Ω 0.1% + 5*
1.0000kΩ 1.2000kΩ 1.9999kΩ 0.08% + 3*
10.000kΩ 12.000kΩ 19.999kΩ 0.06% + 3
100.00kΩ 120.00kΩ 199.99kΩ 0.06% + 3
1.0000MΩ 1.2000MΩ 1.9999MΩ 0.06% + 3
10.000MΩ 12.000MΩ 19.999MΩ 1.5% + 3
100.00MΩ 120.00MΩ 199.99MΩ 5.0% + 5
F
100.0Ω 120.0Ω 199.9Ω 0.1% + 2*
1.000kΩ 1.200kΩ 1.999kΩ 0.08% + 2
10.00kΩ 12.00kΩ 19.99kΩ 0.06% + 2
100.0kΩ 120.0kΩ 199.9kΩ 0.06% + 2
1.000MΩ 1.200MΩ 1.999MΩ 0.06% + 2
10.00MΩ 12.00MΩ 19.99MΩ 1.5% + 2
100.0MΩ 120.0MΩ 199.9MΩ 5.0% + 2
4W Resistance
Note

Max. Input: 500V DC or 500V rms AC

When measuring resistances higher than 500kΩ, please
use shielded test cables to reduce noise interference.
Rate Range
Full Scale
(GDM-8251A) Full Scale
(GDM-8255A) Accuracy
reading%+digits
S
100.000Ω 120.000Ω 199.999Ω 0.05% + 8
1.00000kΩ 1.20000kΩ 1.99999kΩ 0.05% + 5
10.0000kΩ 12.0000kΩ 19.9999kΩ 0.05% + 5
100.000kΩ 120.000kΩ 199.999kΩ 0.05% + 5
1.00000MΩ 1.20000MΩ 1.99999MΩ 0.05% + 5
10.0000MΩ 12.0000MΩ 19.9999MΩ 0.3% + 5
