SCANNER (OPTIONAL)
71
S
CANNER (OPTIONAL)
The optional scanner GDM-SC1 lets you effectively
measure multiple channels connected to a single
GDM-8255A Series DMM.
Installation GDM-SC1 Scanner Specifications .......................... 72
Configure scanner .................................................. 72
Select Channel group and enable scanner.............. 74
Connect wire .......................................................... 75
Insert scanner ........................................................ 77
Scanner Configuration Record ................................ 79
Setup Overview ................................................................ 80
Setup Simple Scan ................................................. 81
Setup Advanced Scan ............................................. 83
Use external trigger ................................................ 85
Run Overview ................................................................ 87
Run Scan/Step ....................................................... 87
Recall Scan/Step result .......................................... 88
Setup and run monitoring ...................................... 88
