GDM-8200A Series User Manual
56
2W* (see Note) ● ● ● ● ●
Hz/P ● ● ● ● ●
TEMP — — — — —
— — — — —
Note

In the dual display mode, the resistance needs to be
larger than 1MΩ.

Some combination of dual display mode is possible but
may not be useful, and their accuracies are not
guaranteed.
2 nd Measurement
item setting
Press the 2nd key, then the target
item (example: ACV). The display
updates the measurement result.
(example: ACI + ACV)
1 st Display Shows the primary measurement result
2 nd Display Shows the secondary measurement result
2ND Indicates that dual measurement is active
Turn Off 2 nd
Measurement
To turn Off the 2 nd measurement,
press and hold the 2 nd key for more
than 1 second.
