APPENDIX
117
AC Current
Note

The specifications are only applicable for sinusoidal
signals with amplitudes greater than 5% of the Full Scale
reading, excluding the GDM-8251A which must have
amplitudes greater than 1.0mA when using a range of
10.0000mA.

mA range protected with a 2A fuse

10A range protected with a 12A, 600V fuse

10mA/100mA range specifications are verified for
< 10kHz

1A/10A range specifications are verified for < 5kHz
Rate Range Resolution
Full Scale
(GDM-8251A) Full Scale
(GDM-8255A)
S
10.0000mA 0.1µA 12.0000mA 19.9999mA
100.000mA 1µA 120.000mA 199.999mA
1.0000A 100µA 1.2000A 1.9999A
10.0000A 100µA 10.0000A 10.0000A
M
10.000mA 1µA 12.000mA 19.999mA
100.00mA 10µA 120.00mA 199.99mA
1.000A 1mA 1.200A 1.999A
10.000A 1mA 10.000A 10.000A
F
10.00mA 10µA 12.00mA 19.99mA
100.0mA 100µA 120.0mA 199.9mA
1.00A 10mA 1.20A 1.99A
10.00A 10mA 10.00A 10.00A
Accuracy (reading%+digits)
Rate
Range 20 ~ 50Hz 50 ~ 10kHz 10k ~ 20kHz
S
10.0000mA 1.5% + 100 0.5% + 100 2% + 200
100.000mA 1.5% + 100 0.5% + 100 2% + 200
1.0000A — 1% + 100 —
10.0000A — 1% + 100 —
M
10.000mA — 0.5% + 40 2% + 80
100.00mA — 0.5% + 12 2% + 30
1.000A — — —
10.000A — — —
F
10.00mA — 0.5% + 5 2% + 10
100.0mA — 0.5% + 2 2% + 5
1.00A — — —
10.00A — — —
