APPENDIX
115
DC Voltage
Note

Max. Input: 1000V DC or Peak on all range
Rate Range Resolution Full Scale
(8251A)
Full Scale
(8255A) Accuracy
S
100.000mV 1µV 120.000mV 199.999mV 0.012%+8
1.00000V 10µV 1.20000V 1.99999V 0.012%+5
10.0000V 100µV 12.0000V 19.9999V 0.012%+5
100.000V 1mV 120.000V 199.999V 0.012%+5
1000.00V 10mV 1000.00V 1000.00V 0.012%+5
M
100.00mV 10µV 120.00mV 199.99mV 0.012%+5
1.0000V 100µV 1.2000V 1.9999V 0.012%+5
10.000V 1mV 12.000V 19.999V 0.012%+5
100.00V 10mV 120.00V 199.99V 0.012%+5
1000.0V 100mV 1000.0V 1000.0V 0.012%+5
F
100.0mV 100µV 120.0mV 199.9mV 0.012%+2
1.000V 1mV 1.200V 1.999V 0.012%+2
10.00V 10mV 12.00V 19.99V 0.012%+2
100.0V 100mV 120.0V 199.9V 0.012%+2
1000V 1V 1000V 1000V 0.012%+2
AC Voltage
Note

The specifications are only applicable for sinusoidal
signals with amplitudes greater than 5% of the Full Scale
reading, excluding the GDM-8251A which must have
amplitudes greater than 10.0mV when using a range of
100.000mV.

(*) Input > 450V only for 30sec, < 200V for 20 ~ 45Hz
Rate Range Resolution
Full Scale
(GDM-8251A) Full Scale
(GDM-8255A)
S
100.000mV 1µV 120.000mV 199.999mV
1.00000V 10µV 1.20000V 1.99999V
10.0000V 100µV 12.0000V 19.9999V
100.000V 1mV 120.000V 199.999V
750.00V(*) 10mV 750.00V 750.00V
M
100.00mV 10µV 120.00mV 199.99mV
1.0000V 100µV 1.2000V 1.9999V
10.000V 1mV 12.000V 19.999V
100.00V 10mV 120.00V 199.99V
750.0V(*) 100mV 750.0V 750.0V
