APS-1102A Control Software User Manual

76

Vertical compression/expansion

As an example of vertical compression/expansion of the waveform, we will generate a trapezoidal

waveform by expanding and clipping the triangle waveform.

Step 1:

Display [New Arbitrary Waveform Editing Panel].
In its initial state, a sine wave is selected.
Select [Triangle] from [Wave] combo box.
Click All-Page OK button to return to waveform display screen.

Step 2:

Click Compress/Expand button on Select Item Panel.
You can also click [Tool] - [Compress/Expand] to obtain the same result.
Select Item Panel is changed to [Compress/Expand Panel].

Step 3:

In the numeric area on the right of [Max], change [32767] to [100000], then press ENTER
key.
In the numeric area on the right of [Min], change [

32767] to [

100000], then press ENTER

key.
In the waveform display section, you can see that the triangle waveform is expanded vertically
and clipped, transforming to a trapezoidal waveform.

Step 4:

Click OK button to return to waveform display screen.

Description 1: You can also use the maximum/minimum numeric values specified in the step 3 to

compress the waveform vertically or move the waveform up or down. If the +/

full scale

is exceeded as a result of the expansion or movement, the waveform will be clipped at the
+/

full scale point.

Description 2: You can compress/expand only a part of a waveform by selecting that part of the

waveform using A marker (red) and B marker (blue) in the waveform display screen
beforehand.

Description 3: If the +/

full scale is not reached by the waveform, you can expand the waveform to

maximum amplitude by clicking Expand with Fixed Offset button or Expand with

Offset Clear button.

Description 4: If the maximum is set to [

100000] and the minimum is set to [100000] in the step 3, the

waveform will be flipped.

Description 5: While you used [Max/Min] to specify the compression/expansion rate in this example, you

can also use [Amplitude/Offset] to do so. Click (option button) on the left of

[Amplitude/Offset] to turn it to

(selected). Next, set [Amplitude] to [200000] and

[Offset] to 0 to obtain the same result as this example.

Description 6: In this example, you generated the trapezoidal waveform by clipping the triangle

waveform. You can generate it more easily by setting [Transition] against the square
waveform.
