5 Sequence
31
5.2.5 Step- transition Parameter Setting
Enter a setting value
Select a cell and then enter a value. If the entered value is out of the setting range, the error dialog
appears. Enter a value according to the dialog.
Select [Termination] from the combo box opened by clicking a cell.
Enter a enable / disable setting value
When a cell of [Stop Phase] or [Jump-to], [Branch] is selected, enable and disable radio buttons become
enabled. If you select the [Enable] radio button, you can set a phase as shown in Figure 5-9.
Clear setting values
Restores a setting value to the default value. Following two methods are available.
 From the Menu Bar, select [Edit] - [Initialize].
 On the keyboard, press Ctrl + I.
Display disabled
Display enabled
Figure 5-9 Enabling or Disabling Start Phase and Stop Phase
