7 Arbitrary Waveform Editing
53
fixed to 4096.
This file can be read with any text editor or spreadsheet software.
Also, a text file created with any text editor or spreadsheet software can be read with the "Arbitrary
waveform editing tool." When creating a text file, include one data per one row. The data must be
16-bit signed integers (

32768 to +32767). Note that the numeric data format is different from that of
the created text file.
As a standard, include 4096 data in a data file. If a file includes more than 4096 data, the excess data is
skipped during the read process. On the other hand, if a file includes less than 4096 data, they are read
into the first part of the waveform and the rest of the waveform will not be changed.
