APS-1102A Control Software User Manual

46

7.4.2 Tool Bar

On the [Arbitrary Waveform Editing] Tool Bar, you just click each icon shown in Figure 7-5 to execute

the corresponding function.

Figure 7-5 Tool Bar in the Arbitrary Waveform Editing Window

a) Open

Opens a waveform information file.

b) Save

Saves the waveform information file.

c)

Memory Transfer

Opens the [Memory Transfer] dialog.

d) Memory Clear

Opens the [Memory Clear] dialog.

7.4.3 Control Panel Section

In the Control Panel section, the control panel that is currently selected is displayed.

Immediately after the Arbitrary waveform editing tool is started or after each operation, the Select Item

Panel is displayed instead.

Create

Interpolate

Compress/Expand

Operate

Select Item Panel

New Arbitrary Waveform

Editing Panel

Interpolate Panel

Operate Panel

Compress/Expand Panel

Figure 7-6 Transitions for Control Panels

7.4.4 Waveform Display Section

In the waveform display section, the image of the created waveform or each type of the coordinates data

is displayed.

a)

b

)

c

)

d

)
