3 Control Software Operation
13
3.6 System Setting
When you first use this software, system setting is needed. Click the System Setting button in the
upper right corner of the window to open the System Setting dialog as shown in Figure 3-8.
You can change the system setting whenever the software is up and running. However, changing the
system setting clears parameters and other settings that are being edited.
Figure 3-8 System Setting Dialog
3.6.1 Connection Type
Specify the type of communication with the APS power source to connect. Select the VISA driver
software. The set communication type is shown in the status bar ( 3.5.3).
3.7 Error Message
You might see some error message in the dialog while using the software. In that case, handle the error
according to the instruction described in the message.
