APS-1102A Control Software User Manual
62
7.8.5 Created Arbitrary Waveforms Examples
Standard waveform
As an example of standard waveform, we will create a triangle wave of 30% symmetry.
Step 1: Click Create button on Select Item Panel.
You can also click [Tool] - [Create] to obtain the same result.
Select Item Panel is changed to [New Arbitrary Waveform Editing Panel].
Step 2: Click button on the right side of [Wave], and then click [Triangle] in the list.
Step 3: In value input section on the right side of [Symmetry], change the value from [50] to [30], and
then press ENTER key. This specifies a triangle wave of 30% symmetry.
Step 4: Click All-Page OK to close [New Arbitrary Waveform Editing Panel] and display the
generated waveform in the waveform display section.
Description 1: In this example, a waveform is generated over entire horizontal axis (X). In the "Arbitrary
waveform editing tool", a waveform can be divided into two or more pages, for
example, the first 1/4 of a waveform to page 1, the last 1/2 to page 2, and others. In this
case, specified effective waveforms on multiple pages can be executed all at once by
clicking All-Page OK button. If you want to execute only the waveforms displayed on
the current page, click Page OK button. In the example above, since page 1 is the only
page specified, the result is same for clicking either button.
Description 2: You can select sine wave, square wave (variable duty ratio), noise, DC, and waveform
definition by a formula (waveform function), as well as triangle wave.
