UNIT 4: SL 2: FCX-2XGC 2-port 16G Module (2-CX4)
==========================================================================
UNIT 4: SL 3: FCX-2XG 2-port 10G Module (2-XFP)
==========================================================================
UNIT 8: SL 1: FCX-48G POE 48-port Management Module
P-ENGINE 0: type DB90, rev 01
P-ENGINE 1: type DB90, rev 01
==========================================================================
UNIT 8: SL 2: FCX-2XGC 2-port 16G Module (2-CX4)
==========================================================================
800 MHz Power PC processor (version 33/0022) 144 MHz bus
65536 KB flash memory
256 MB DRAM
Monitor Option is on
STACKID 8 system uptime is 21 hours 2 minutes 23 seconds
STACKID 2 system uptime is 21 hours 2 minutes 22 seconds
STACKID 3 system uptime is 21 hours 2 minutes 23 seconds
STACKID 4 system uptime is 21 hours 2 minutes 22 seconds
The system : started=warm start reloaded=by "reload"
My stack unit ID = 8, bootup role = active
*** NOT FOR PRODUCTION ***
NOTE
For field descriptions for the show-running config command, refer to the “Displaying running
configuration information.”
NOTE
For field descriptions for the show stack and show stack detail commands, refer to the “Displaying
stack information.”
The output from the show stack command contains a visual diagram of the stack. The dashed line
between ports 1/2/1 and 3/2/1 indicates that this stack is configured in a ring topology. If the link
between ports 1/2/1 and 3/2/1 is lost, the stack topology changes to linear, and the diagram changes to
resemble the following.
active standby
+---+ +---+ +---+
-2/1| 1 |3/1--2/1| 2 |3/1--2/2| 3 |2/1-
+---+ +---+ +---+
The interfaces at either of a stack member are stacking ports. If no interface is displayed, it indicates
that there is no stacking port configured. For example, the following diagram shows that stack units 1
and 3 each have only one stacking port configured.
active standby
+---+ +---+ +---+
| 1 |3/1--2/1| 2 |3/1--2/2| 3 |
+---+ +---+ +---+
For more detailed information, you can enter the show stack detail command.
Brocade traditional stack management
Your Brocade traditional stack can be managed through a single IP address. You can manage the stack
using this IP address even if you remove the active controller or any member from the stack. You can
also connect to the active controller through Telnet or SSH using this address. All management
functions, such as SNMP, use this IP address to acquire MIB information and other management data.
A Brocade traditional stack can be configured and managed using the command line interface (CLI)
over a serial connection to a console port.
