M series service manual – ZOLL M Series Defibrillator Rev R User Manual
Page 83
M Series Service Manual
73
USE PADS
(AUTO DEFIB MODE ONLY.)
Attempt to defib with paddles in auto defib (AED)
mode. Defib only allowed using PADS in AED
modes.
USE PADS TO PACE
External paddles detected in pace mode.
USE ROOM AIR
ADAPTER
Adapter zeroing started with EtCO
2
in the adapter or
the adapter is on the REF or “0” cell.
Place CO
2
sensor on
adapter in room air.
USER SETUP REQ
Both copies of stored cal/config data are bad or have
never been programmed.
Perform configuration
setup.
VF ALARMS OFF
VF alarms disabled in pace mode or when paddles
are selected as leads.
VX LEADS OFF
V lead not properly attached to patient. “X” denotes
lead number.
Reattach V lead.
ZERO CO
2
SENSOR
New EtCO
2
sensor needs to be zero calibrated.
Zero EtCO
2
sensor.
ZERO CO
2
ADAPTER
New EtCO
2
airway adapter needs to be zero
calibrated.
Zero EtCO
2
adapter.
Error Message
Explanation
User
Advisory
Technical Action
