M Series Service Manual
25
12.0 Synchronized Cardioversion Test
Tools Needed:
QED 6 Defibrillator Analyzer.
Test Setup:
Connect the universal cable via the adapter (D.N.I #3010-0378) to the defibrillator analyzer.
Select Sync on analyzer and set ECG on analyzer to 60 -120 BPM.
Do this...
Verify that...
Pass/
Fail
12.1
Press LEAD button to select
PADS and Size X1.
12.2
Press the SYNC softkey on the
defibrillator. Enter synchronized
cardioversion timing test mode on
the defibrillator analyzer.
Sync markers appear on display.
Note:
Sync markers display on the monitor. The sync
marker appears as a down arrow over the ECG
R-wave peaks on strip chart and display.
o
o
12.3
Select 200J (360J for Monophasic
units), and then press the
CHARGE button. When the
SHOCK button lights, press and
hold the SHOCK button.
On the analyzer display, the R-wave to shock delay is
less than60 milliseconds.
o
o
Record your results on the Maintenance Tests Checklist.
