0 heart rate alarm test, M series service manual – ZOLL M Series Defibrillator Rev R User Manual
Page 31
M Series Service Manual
21
10.0 Heart Rate Alarm Test
Tools Needed:
QED 6 Defibrillator Analyzer
Do this...
Verify that...
Pass Fail/
NA
10.1
Turn the selector switch to
MONITOR mode.
(For AED units, turn the selector
switch to ON and select Manual
mode.)
Connect the ECG leads to the
QED 6 Defibrillator Analyzer
.
Set
the QED 6 Analyzer to 120 BPM
and the defibrillator to lead II.
The monitor screen displays the Lead II message and
the waveform for NSR ECG at 120 BPM +/- 2
.
o
o
o
10.2
Press ALARMS button.
The monitor displays the alarm menu.
o
o
o
10.3
Press SELECT PARAM softkey
until ECG HR displays.
The cursor scrolls through parameters.
o
o
o
10.4
Press INC> for state.
The cursor scrolls through ENABLE, AUTO and
DISABLE.
o
o
o
10.5
Press DEC>for state.
The cursor scrolls through ENABLE, DISABLE, AND
AUTO.
o
o
o
10.6
Press INC> until ENABLE
displays.
ENABLE appears.
o
o
o
10.7
Press ENTER softkey, then press
the NEXT FIELD softkey to
select the heart rate limit.
The cursor scrolls to Low field. Press RETURN softkey
to exit out of Alarm Menu.
o
o
o
10.8
Press ALARM SUSPEND
button.
No alarm sounds.
o
o
o
