M Series Service Manual
16
6.0 Paddles Test (If applicable)
Tools Needed: QED 6 Defibrillator Analyzer.
Test Setup: If applicable, connect the universal cable to the paddles and place the paddles in paddle wells.
Do this... Verify that... Pass/Fail/
NA
6.1 Turn the selector switch to
DEFIB (For AED units,turn the
selector switch to ON and
select Manual mode.) Press
and hold the ENERGY DOWN
button on the sternum paddle. The energy selection decreases to 1J. o o
6.2 Press and release the ENERGY
UP button on the sternum paddle
for each setting. The joules selection increases as follows: Biphasic 1-
10, 15, 20, 30, 50, 75, 100, 120, 150, 200J.
Monophasic (DSW): 1-10,15, 20, 30, 50, 75, 100, 150,
200, 300, 360.
o o
6.3 Press and release the
RECORDER button on the
sternum paddle. The recorder starts printing. o o o
6.4 Press and release the
RECORDER button again. The recorder stops printing. o o
6.5 Select 30J using the paddle
ENERGY button. Press the
CHARGE button on the Apex
paddle. The unit charges to 30J, then the red LED charge
indicator illuminates and the charge tone sounds.
Note: The front panel shock button does not
illuminate.
o o
6.6 Press and release the APEX
SHOCK button. The unit does not discharge. o o
6.7 Press and release the
STERNUM SHOCK button. The unit does not discharge. o o
6.8 Press and hold both paddles
SHOCK buttons. The unit discharges. The TEST OK message displays
and the red LED turns off. If configured, the recorder
prints a strip chart. o o
