Page 40
M Series Service Manual
30
15.0 Advisory Message Test
Tools Needed:
QED 6 Defibrillator Analyzer.
Test Setup:
Connect the universal cable via the adapter (D.N.I #3010-0378).
Attach the M Series to the QED 6 Defibrillator Analyzer.
Do this...
Verify that...
Pass/
Fail
15.1
Turn the selector switch to DEFIB
mode.
(For AED units, turn the selector
switch to ON.)
15.2
Select VF (ventricular fibrillation)
on the QED 6, then press the
ANALYZE button.
The unit displays the following messages:
ANALYZING ECG.
STAND CLEAR.*
SHOCK ADVISED.*
PRESS SHOCK.*+
*AED’s audio prompts are standard. Advisory audio
prompts are user configurable.
+If configured for auto charge.
o
o
15.3
Press the SHOCK button.
The unit discharges.
o
o
15.4
Select the NSR (normal sinus
rhythm) on the simulator, then
press the ANALYZE button.
The unit displays the following messages:
ANALYZING ECG.
STAND CLEAR.*
NO SHOCK ADVISED.*
*AED’s audio prompts are standard.
o
o
Record your results on the Maintenance Tests Checklist.
