M series service manual – ZOLL M Series Defibrillator Rev R User Manual
Page 47

M Series Service Manual
37
18.4
On the Novametrix simulator,
set% CO
2
to 5%.
The EtCO
2
reading of 34-42mmHg displays on the M
Series monitor. The Respiration Rate (RR) of 22-24
displays on the M Series monitor.
Note that you may need to wait up to 10 seconds for the
unit to stabilize.
o
o
18.5
Press WAVE 2 softkey
For CCT units: Press the Trace
softkey, select SET TRACE 2,
and press Enter. Select EtCO2,
press Enter.
Verify the EtCO
2
waveform displays.
o
o
18.6
Press the RECORDER button.
Verify the EtCO
2
waveform prints
Note that the CO
2
waveform is displayed and printed at
12.5 millimeters per second scale.
o
o
Record your results on the Maintenance Tests Checklist.
Do this...
Verify that...
Pass/
Fail
