M series service manual – ZOLL M Series Defibrillator Rev R User Manual
Page 69
M Series Service Manual
59
AUDIO FAULT 136
Audio DSP hardware error.
Replace audio board.
Replace system
board.Turn unit off and
back on again.
AUDIO NOT
RECORDING
Audio is not recording.
Install PCMCIA card.
Replace system board.
AUDIO QUEUE FULL
Indicates that the audio output queue is full.
Additional voice prompts can't be queued at this
time.
None.
BATT HIGH CURRENT
Battery is charged and battery current is >.1 A or:
Battery is not charged and battery current is > 1.6 A.
Unplug from A/C.
Remove the battery for
20 seconds. Reconnect
all above. If the
problem persists,
replace battery and or
charger.
BATT HIGH VOLTAGE
Battery voltage > 15.5 v.
Replace battery and or
charger
BATT LOW CURRENT
Battery is not charged and battery current is <.35 A.
Replace battery and or
charger.
BATT LOW VOLTAGE
Battery voltage < 9.5 v.
Replace battery and or
charger.
BATT OVERCHARGE
Charger on for > 4 hours.
Replace battery and or
charger.
Error Message
Explanation
User
Advisory
Technical Action
