M Series Service Manual
13
Test Setup
Remove red lead from power supply and connect to 0.1ohm resistor.
Connect other end of resistor to “+” terminal of power supply using a second red label.
Connect multimeter across the resistor.
Set voltage scale (if DVM is not autoranging) to 220mV.
Do this....
Observe this...
Pass/
Fail/
4.7
System Current Test
Set power supply to 10.3V.
15 Amp
Supply
+
_
DMM
_
+
+
_
Battery Well
Red
Black
