M Series Service Manual
71
SET PACE RATE
Multiple copy errors are the product of intended
software or memory errors. Multiple copies of pace
rate don't match. If error persists, unit could be
broken
Set pace rate. If broken,
replace system board.
SHOCK ADVISED
Advisory message when analysis finds a shockable
rhythm.
SpO
2
AMBIENT LIGHT
Ambient light is too bright.
Shield sensor from
ambient light. Replace
Sp0
2
sensor. Replace
Sp0
2
module
SpO
2
COMM ERR
No transmissions from SpO
2
unit received.
Communication error or no communication from
Sp0
2
module.
Replace Sp0
2
module
and/or system board.
SpO
2
PULSE SEARCH
Pulse search in progress.
SpO
2
SENSOR FAULT 1
Defective sensor.
Replace Sp0
2
sensor.
SpO
2
SENSOR FAULT 5
Unrecognized sensor.
Replace Sp0
2
sensor.
STAND CLEAR
(Auto defib mode only.) Single analysis mode just
turned on and defib idle. Patient rhythm is being
analyzed.
SYSTEM FAULT 2
MCU ROM checksum test failure or MCU RAM test
failure.
Turn off unit and then
turn on to reset. If fault
persists, replace system
board.
Error Message
Explanation
User
Advisory
Technical Action
