M Series Service Manual
27
13.8
Press the ENERGY SELECT up
arrow until the unit displays 100J.
The unit displays the message, DEFIB 100J SEL.
o
o
o
13.9
Press the CHARGE button. Wait
for the SHOCK button to
illuminate.
The unit displays the message, DEFIB 100J RDY.
o
o
o
13.10
Press the SHOCK button.
The unit discharges 83J-122J (monophasic 85J-115J)
into the simulator.
o
o
o
13.11
Press the ENERGY SELECT up
arrow until the unit displays 200J.
The unit displays the message, DEFIB 200J SEL.
o
o
o
13.12
Press the CHARGE button. Wait
for the SHOCK button to
illuminate.
The unit displays the message, DEFIB 200J RDY.
o
o
o
13.13
Press the SHOCK button.
The unit discharges 182J-247J (monophasic 170J-
230J) into the simulator.
o
o
o
13.14
(Monophasic Units) Press the
ENERGY SELECT up arrow unit
the unit displays 300J.
The unit displays the message, DEFIB 300J SEL.
o
o
o
13.15
Press the CHARGE button. Wait
for the SHOCK button to
illuminate.
The unit displays the message, DEFIB 300J RDY.
o
o
o
13.16
Press the SHOCK button.
The unit discharges 255J-345J into the simulator.
o
o
o
13.17
(Monophasic Units) Press the
ENERGY SELECT up arrow unit
the unit displays 360J.
The unit displays the message, DEFIB 360J SEL.
o
o
o
13.18
Press the CHARGE button. Wait
for the SHOCK button to
illuminate.
The unit displays the message, DEFIB 360J RDY.
o
o
o
13.19
Press the SHOCK button.
The unit discharges 306J-414J into the simulator.
o
o
o
Do this...
Verify that...
Pass/Fail/
NA
