M Series Service Manual
36
18.0 EtCO
2
Monitor Test (for EtCO
2
Option)
Tools Needed: Novametrix Capnostat Simulator Tb 1265/7100.
Test Setup: Install the battery
On the Novatrix Simulator, set the folling
Set inspired CO
2
to OFF
Set% CO
2
to 0
Set Sensor Location to ZERO CELL
Set Source Current to NORMAL
Set CO
2
mode to CONTINUOUS. Set Temperature to NORMAL
Attach simulator to the unit.
Do this... Verify that... Pass/
Fail
18.1 Turn the selector switch to
MONITOR mode (For AED units,
turn the selector switch to ON,
and select Manual mode.) Attach
the EtCO
2
simulator to the M
Series input connection.
CO
2
SENSO WARMUP message displays.
Note: You may need to wait up to 5 minutes for the
warm-up message to disappear.
o o
18.2 Perfom manual zeroing. Press
PARAM softkey, select EtCO
2
,
press ENTER, and then press
ZERO softkey, then Enter.
Verify “ZEROING CO2” Adapter” is displayed, then
changes to “ZERO DONE” when complete. o o
18.3 On the Novametrix SImulator, set
SENSOR LOCATION to AA
CELL, set% CO
2
to 10% CO
2
mode to RESPIRATION.
Verify the EtCO
2
reading of 74-84mmHg appears on the
M Series display.
Note that you may need to wait up to 10 seconds for the
unit to stabilize.
o o
