M series service manual – ZOLL M Series Defibrillator Rev R User Manual
Page 76
M Series Service Manual
66
ECG V6 LEAD OFF
Chest lead V6 is not properly attached to patient.
Reattach V lead. Check
cable.
ENTER ACCESS CODE
Manual mode access code needed.
Enter access code to
enter manual mode
with AED.
ERASING REPORT
Summary report being erased.
ECU CRC FAULT
Invalid ECG samples detected over a one second
period.
Turn off unit and then
turn on to reset. If fault
persists, replace system
board.
EtCO
2
COM ERROR
No or invalid communication from EtCO
2
module.
Return unit for service
to ZOLL Technical
Service Department.
FAX DIALING
Preparation for sending fax.
FAX DONE
Transmission complete.
FAX PREPARING
Preparing fax for transmission.
FAX SENDING
Transmitting fax.
INSERT CARD
Check memory card
No card installed in unit during manual or semi-
automated modes.
LOW BATTERY
Low battery.
Replace battery or plug
into AC power. Replace
charger.
NO QRS DETECT
Unit is in sync mode and heart rate is < 20 BPM or
QRS amplitude is too low for proper
synchronization.
Increase ECG size and/
or change lead.
Error Message
Explanation
User
Advisory
Technical Action
