5.4.6. SP298 PRINTER SETTINGS, CONTINUED
DIP Switch Settings (SERIAL INTERFACE)
SWITCH
FUNCTION
ON
OFF
1
Baud Rate
See table below.
2
3
Data Length
8 bits
7 bits
4
Parity Check
Disabled
Enabled
5
Parity
Odd
Even
6
Handshake
DTR/DSR
XON/XOFF
7
Command Emulation
See table below
8
9
Pin #6 (DSR) reset signal
Enabled
Disabled
10
Pin #25 (INIT) reset signal
Enabled
Disabled
Baud Rate Settings Table
BAUD RATE
SWITCH 1
SWITCH 2-2
4800 bps
OFF
ON
9600 bps
ON
ON
1920 bps
ON
OFF
3840 bps
OFF
OFF
Command Emulation Table
COMMAND
EMULATION
SWITCH 7
SWITCH 8
Star Mode
ON
ON
ESC/POS (TM-295)
ON
OFF
ESC/POS (TM-290)
OFF
OFF
Not used (*)
OFF
ON
* Never set Switch 7 to
OFF
at the same time that Switch 8 is set to
ON
.
