Section 9 Network Application Configuration
07/2012 165 51254 Rev. 3
D. FIELD BUS DATA REPRESENTATION, CONTINUED
WORD BYTE REGISTER USAGE SIZE(BYTES) SCALE
30 60 - 61 Command Word 0 2 Scale 4
31 62 - 63 Command Word 1 2
32 64 - 65 Command Word 2 2
33 - 34 66 - 69 Setpoint 1 4
35 - 36 70 - 73 Setpoint 2 4
37 - 38 74 - 77 Tare Weight 4
39 78 – 79 Unassigned 2
80 - 105 Display Message Line 1 26 All Scales
106 - 131 Display Message Line 2 26
132 - 157 Display Message Line 3 26
INPUT DATA (WORD BYTE REGISTER USAGE)
WORD BYTE REGISTER USAGE SIZE(BYTES) SCALE
0 0 - 1 Status Word 0 2 Scale 1
1 2 - 3 Status Word 1 2
2 4 - 5 Status Word 2 2
3 - 4 6 - 9 Unassigned 4
5 - 6 10 - 13 Gross Weight 4
7 - 8 14 - 17 Tare Weight 4
9 - 10 18 - 21 Net Weight 4
11 - 12 22 - 25 Setpoint 1 4
13 – 14 26 - 29 Setpoint 2 4
15 - 16 30 - 33 Flow Rate (weight /second) 4
17 - 19 34 - 39 Unassigned 6
