D. field bus data representation, continued – Fairbanks FB2550 SERIES User Manual
Page 167
Section 9 Network Application Configuration
07/2012
167
51254 Rev. 3
D. FIELD BUS DATA REPRESENTATION, CONTINUED
WORD
BYTE
REGISTER USAGE
SIZE(BYTES)
SCALE
60
120 - 121
Status Word 0
2
Scale 2
61
122 - 123
Status Word 1
2
62
124 - 125
Status Word 2
2
63 - 64
126 - 129
Unassigned
4
65 - 66
130 - 133
Gross Weight
4
67 - 68
134 - 137
Tare Weight
4
69 - 70
138 - 141
Net Weight
4
71 - 72
142 - 145
Setpoint 1
4
73 - 74
146 - 149
Setpoint 2
4
75 - 76
150 - 153
Flow Rate (weight /second)
4
77 - 79
154 - 159
Unassigned
6
