07/2012 123 51254 Rev. 3
Section 6: Traffic Light Control
6.1. TRAFFIC LIGHT CONTROL
The TRAFFIC LIGHT CONTROL shows the status of the scale’s traffic light. It
is typically controlled automatically by the instrument weighment cycle.
•
The light has a manual override using the touch screen on the main weighing
display.
•
Each of the two (2) I/O RELAY CARDS supports two (2) sets of lights,
totaling four (4) Stop Light Units.
Follow these steps to configure the Traffic Light Control.
1. Select LOGIN.
2. Enter the Supervisor Password or
Service Password.
3. Open the CONFIGURATION
MENU.
4. Press PAGE FORWARD twice.
5. Select TRAFFIC LIGHT
CONTROL .
6. Select SCALE ID X TRAFFIC
CONTROLS .
