Section 5: Input/ Output
07/2012 67 51254 Rev. 3
5.4.2. HP P2055d LASERJET PRINTER SETTINGS,
CONTINUED
Control Panel Access
Program the paper type and size through the Control Panel Access.
NO. BUTTON or
LIGHT
FUNCTION
1 Control-panel
display
Shows status information, menus, and error messages.
2 ▲ UP arrow Navigates to the next submenu or the next value in a menu
selection list, moves the cursor forward a single position, or
increases the value of numeric items.
3 OK button
•
Saves the selected value for an item
•
Performs the action that is associated with the item that is
highlighted on the control-panel display.
•
Clears an error condition when the condition is clearable.
4 ▼ DOWN arrow Navigates to the next item in the list, or decreases the value of
numeric items.
5 BACK button BACKS UP one level in the menu tree or backs up one numeric
entry.
6 Ready light • ON – The product is online and ready to accept data to print.
• OFF – The product cannot accept data because it is offline
(paused) or has experienced an error.
•
Blinking: The product is processing a job.
7 CANCEL
button
CANCELS the current print job
8 ERROR Light
• OFF – The product is functioning without error.
• BLINKING – Action is required. See the Control-panel
Display.
