Instrument configuration – printers, continued – Fairbanks FB2550 SERIES User Manual
Page 59
Section 5: Input/ Output
07/2012
59
51254 Rev. 3
5.2. INSTRUMENT CONFIGURATION – PRINTERS, CONTINUED
18. Set the data protocol for the COM
Port, including the
PRINTER,
BAUD RATE, PARITY, DATA
BITS
and
STOP BITS
.
The FB2550 will indicate the port has been
set and the defaults loaded.
19. If this is the first time the printer is installed on the Indicator, load the
PRINTER DEFAULT FORMATS by pressing the
YES
button.
20. Press the
SAVE CHANGES
button on the touch screen display to
complete the Printer configuration.
•
Select
BACK
:
CONFIGURATION
MENU
to return to the Configuration
Menu.
21. Connect the printer cable to the
printer and the configured COM
port.
