Fairbanks FB2550 SERIES - Manual (Page 104)

Section 5: Input/ Output
07/2012 104 51254 Rev. 3
5.8.4. METHOD 2 - CUSTOMIZING DATA STRINGS,
CONTINUED
29. Press PAGE FORWARD once
again.
– This page configures the Mode:
token for the output data string.
– Each item configured will indicate the
character(s) programmed in the
output data string.
– The Remote Commands:
configuration establishes if a carriage return is required when sending a
remote command, such as a Zero Command.
– If the check box is selected, the remote Zero Command is Z .
Otherwise it would be a “Z” only.
30. Press the SAVE CHANGES button when any changes are made.;
Otherwise, the changes will be lost.
•
Selecting BACK: CONFIGURE COM1 will return the user to the Configure
COM1 Menu.
31. Touch RETURN TO WEIGHING to test and verify the output is
producing the desired results.
