MGP Pro Series • Remote Configuration and Control 62
Command
ASCII (Telnet)
(Host to Processor) Response
(Processor to Host)
Additional Description
Special Functions (continued)
Set output sync format
2 * X3& # Syn X3& ] Set the output sync format.
For
X3& :
1 = RGBHV
2 = RGBS
3 = RGsB
4 = YUV bi-level
5 = YUV tri-level.
View output sync format 2 # X3& ] View current output sync format
setting
X3& .
Set blue mode to On or Off 3 * X$ # Blu X$ ] Turn blue mode on and off.
Blue mode is useful when you
are configuring display color
settings.
For
X$ :
0 = blue mode off.
1 = blue mode on.
View blue mode status 3 # X$ ] View the current blue mode
status.
Set text position 6 * X@ * X^ # X@ Tlc X^ ] Change the location of the text
label to
X^ in window X@ .
X@ = 0-4. 0 = all windows.
For X^ :
0 = None
1 = Bottom left
2 = Bottom center
3 = Bottom right
4 = Top left
5 = Top center
6 = Top right.
View text position 6 * X@ # X^ ] View the text label position ( X^ )
in window X@ .
Set text size 10 * X3* # Tsz X3* ] Set the size of the label text.
For
X3* :
1 = Small
2 = Medium
3 = Large.
View text size 10 # X3* ] View the current size ( X3* ) of
the label text.
Set text border color 14 * X@ * X3( # X@ Txb X3( ] Change the color of the text
label border in window
X@ .
X@ = 0-4. 0 = all windows.
For X3( :
0 = Off (no border)
1 = Red
2 = Green
3 = Blue
4 = White
5 = Magenta
6 = Cyan
7 = Yellow
8 = Black
9 = Translucent.
View text border color 14 * X@ # X3( ] View the border color ( X3( ) of
the text label in window X@ .
