MGP Pro Series • Remote Configuration and Control 47
X1@ = Window transition effect type
1 = Cut
2 = Dissolve
3 = Soft wipe up
4 = Soft wipe down
5 = Soft wipe right
6 = Soft wipe left
7 = Soft wipe center in
8 = Soft wipe center out
9 = Soft wipe square in
10 = Soft wipe square out
11 = Soft wipe curtain in
12 = Soft wipe curtain out
13 = Hard wipe up
14 = Hard wipe down
15 = Hard wipe right
16 = Hard wipe left
17 = Hard wipe center in
18 = Hard wipe center out
19 = Hard wipe square in
20 = Hard wipe square out
21 = Hard wipe curtain in
22 = Hard wipe curtain out
X1# = Blanking adjustment range (0-255). Default = 128.
X1$ = Window preset (1-128)
X1% = Input preset (1-128)
X1^ = Scaler refresh rate
0 = Match output or user defined rates (applies to
EDID command only)
1 = 50 Hz
2 = 60 Hz
3 = 72 Hz
4 = 96 Hz
5 = 100 Hz
6 = 120 Hz
7 = Live background input refresh rate
8 = 24 Hz
9 = 59.94 Hz
10 = 29.97 Hz
11 = 30 Hz
NOTE: All input EDID resolutions have available
refresh rates of 50 Hz and 60 Hz only except:
• 576p has 50 Hz only.
• 480p, Sharp 1080p, and 1080p CVT have
60 Hz only.
X1& = Pixel phase (0-31)
X1* = Advanced picture settings value
(Range is the auto-sensed value ±512 lines or pixels.)
X1( = Window dissolve speed: 0 to 5 seconds in
0.1-second increments.
Example: 01 = 0.1 second, 50 = 5.0 seconds)
X2) = Internal temperature in degrees Fahrenheit
X2! = Image or window position (Zero location is 2048, and
limits are ± the output resolution.)
Example: Front panel displays
+50, but the response
to the SIS command is 2098.
X2@ = Window size. The minimum size is 1/16 the size of
the output active area. The maximum size is double
the active output area.
X2# = Image size. The minimum size is 1/16 the size of the
input active area. The maximum size is double the
active output area for 200% zoom.
X2$ = Window preset effect
0 = Cut
1 = Real time motion. If this is entered, recalling a
window preset with the windows in new positions
causes the windows to move to the new location and
resize in a fluid motion.
X2% = Red, green, or blue color value (0-255)
X2^ = Window priority (1-4, where 1 is top priority and 4 is
lowest priority)
X2& = EDID table, 128 or 256 bytes (binary—machine
readable only)
X2* = EDID table, 128 or 256 bytes (hexadecimal—person-
readable)
X2( = HDCP status (valid only with HDMI inputs and
outputs)
0 = No source or sink detected
1 = Source or sink with HDCP detected
2 = No source or sink with HDCP detected
X3) = HDCP output setting
0 = Auto (default). Digital outputs are encrypted only
when an encrypted input is connected. Switching
is slower and problems with output sync may
occur.
1 = On. Digital outputs are always encrypted,
regardless of input selection. Switching is faster.
X3! = HDMI output format
0 = Auto (based on sink EDID)
1 = DVI 444 RGB (0-255, no InfoFrames)
2 = HDMI 444 RGB (0-255, InfoFrames)
Default is 0.
X3@ = Virtual window number (0-256)
X3# = Virtual input number (0-256)
X3$ = HDMI input HDCP authorization status
0 = HDCP encrypted data blocked
1 = HDCP encrypted data allowed
Default is 1.
X3% = Front panel lock (executive mode) status
0 = Unlocked
1 = Locked except for input selection buttons
2 = All controls locked
NOTE: Front panel lockout does not include
RS-232, RS-422, and Ethernet control.
