MGP Pro Series • Remote Configuration and Control
46
MGP Pro commands
X!
= Input number (1-20). 20 = live background (for
HDCP status only)
X@
= Window number
0 = All windows (available only for freeze and window
mute)
1 = Window 1
2 = Window 2
3 = Window 3 (MGP 464 Pro models only)
4 = Window 4 (MGP 464 Pro models only)
X#
= Input video format
1 = RGB
2 = YUV-HD
3 = RGBcvS
4 = YUVi
5 = S-video
6 = Composite video
7 = HDMI or 3G/HD-SDI
X$
= On or off status
0 = off or disabled
1 = on or enabled
X%
= Test pattern
0 = Off
1 = Colorbars
2 = X-Hatch (crosshatch 16 x 12)
3 = 4 x 4 X-Hatch
4 = Grayscale
5 = Ramp
6 = Alt. pixels (alternating pixels)
7 = White field
8 = Crop
9 = Side-By-Side (4 x 3 crop)
10 = Quad Split (4 x 4)
11 = PIP Images (4 x 3 or 16 x 9 PIP column)
12 = 1.78 Aspect (4 x 3 or 16 x 9 with 1.78 film
aspect ratio)
13 = 1.85 Aspect (4 x 3 or 16 x 9 with 1.85 film
aspect ratio)
14 = 2.35 Aspect (4 x 3 or 16 x 9 with 2.35 film
aspect ratio)
NOTE: Patterns 10 and 11 are not available on
the MGP 462 Pro models.
X^
= Window text position
0 = None
4 = Top left
1 = Bottom left
5 = Top center
2 = Bottom center
6 = Top right
3 = Bottom right
X&
=
Window text, 16 characters maximum. The following
characters can be used:
Symbols: / : – _ + “ {space}
Numerals: 0-9
Letters: Lowercase a-z and uppercase A-Z
X*
=
Picture adjustment range (applies to color, tint,
brightness, and contrast)
(0-127. Default = 64)
X(
=
Scaler resolution
0 = Match output rate (
1 = 640 x 480
2 = 800 x 600
3 = 852 x 480
4 = 1024 x 768
5 = 1024 x 852
6 = 1024 x 1024
7 = 1280 x 768
8 = 1280 x 1024
9 = 1360 x 765
10 = 1365 x 768
11 = 1366 x 768
12 = 1365 x 1024
13 = 1400 x 1050
14 = 1600 x 1200
15 = 480p
16 = 576p
17 = 720p
18 = 1080i
19 = 1080p
20 = Live background input resolution (
21 = 1280 x 800
22 = 1360 x 768
23 = 1440 x 900
24 = 1680 x 1050
25 = 1080p Sharp
26 = 1920 x 1200
27 = 1080p CVT
28 = 2048 x 1080
99 = Custom (
X1)
= Detected input signal standard
0 = none
1 = NTSC
2 = PAL
4 = SECAM
– = Not applicable (occurs when input is set for RGB
or YUV)
X1!
= Sharpness (detail) level (0-127)
