MGP Pro Series • Remote Configuration and Control

55

Command

ASCII (Telnet)
(Host to Processor)

Response
(Processor to Host)

Additional Description

Vertical Shift (Image)
Set a specific value

2 *

X@

*

X2!

/

X@

Ivp

X2!

]

Set the vertical centering of the
image in window

X@

to

X2!

.

X@

= 0-4. 0 = all windows.

For

X2!

:

0 = 2048. Limits are ± the

output resolution.

Increment vertical image shift

2 *

X@

+ /

X@

Ivp

X2!

]

Shift image in window

X@

up.

Decrement vertical image shift

2 *

X@

– /

X@

Ivp

X2!

]

Shift image in window

X@

down.

View vertical image shift
amount

2 *

X@

/

X2!

]

View the current setting for
vertical centering of the image
in window

X@

.

Horizontal Size (Window)
Set a specific value

1 *

X@

*

X2@

:

X@

Whs

X2@

]

Set the width of window

X@

to

X2@

. For

X2@

:

Minimum = 1/16 the size of the
active output area.
Maximum = size of the active
output area.

Increase horizontal size of
window

1 *

X@

+ :

X@

Whs

X2@

]

Widen the window.

Decrease horizontal size of
window

1 *

X@

– :

X@

Whs

X2@

]

Narrow the window.

View horizontal size of window

1 *

X@

:

X2@

]

View the width of the window.

Vertical Size (Window)
Set a specific value

1 *

X@

*

X2@

;

X@

Wvs

X2@

]

Set the height of window

X@

to

X2@

.

Increase vertical size of
window

1 *

X@

+ ;

X@

Wvs

X2@

]

Increase the height of the
window.

Decrease vertical size of
window

1 *

X@

– ;

X@

Wvs

X2@

]

Decrease the height of the
window.

View vertical size of window

1 *

X@

;

X2@

]

View the height of the window.

Horizontal Size (Image)
Set a specific value

2 *

X@

*

X2#

:

X@

Ihs

X2#

]

Set the width of the image in
window

X@

to

X2#

. For

X2#

:

Minimum = 1/16 the size of the
active input area.
Maximum = double the active
output area for 200% zoom.

Increase horizontal size of

2 *

X@

+ :

X@

Ihs

X2#

]

Widen the image.

Decrease horizontal size of

2 *

X@

– :

X@

Ihs

X2#

]

Narrow the image.

View horizontal size of image

2 *

X@

:

X2#

]

View the width of the image.
