IN1606 and IN1608 Series Scaling Presentation Switcher • Internal Web Pages 66
EDID Minder Page
EDID Minder is an EDID management process that manages the EDID information between
the scaler and one or more input sources. Click the
EDID Minder icon on the Global
Navigation Bar to open the EDID Minder page.
Figure 37. EDID Minder Page
The EDID properties currently assigned to each input are displayed in the table of inputs.
The audio input format listed in an EDID is determined by the audio input format selected on
the Audio Configuration page (unless a custom EDID is used).
Audio Input Format Audio Capabilities Listed in EDID
None No audio
Analog No audio
LPCM-2Ch 2-channel audio
Multi-Ch Multi-channel audio
LPCM-2Ch Auto 2-channel audio
Multi-Ch Auto Multi-channel audio
EDID can be stored or imported as custom EDID files. Up to six or eight EDID files can be
stored on the scaler depending on the scaler model. Audio settings from custom EDID files
take priority over current settings on the input.
NOTE: If an analog custom EDID file is assigned to a digital input or a digital custom
EDID file assigned to an analog input, the display may not appear correctly.
Filtering Available EDID
Use the Filter tab to limit the number of available EDID displayed in the Available EDIDs
and Connected Outputs sections.
1. From the Resolution drop-down menu, select a specific resolution or Any .
2. From the Refresh Rate drop-down menu, select a specific refresh rate or Any .
