IN1606 and IN1608 Series Scaling Presentation Switcher • Operation 15
Powering Up
When power is applied to the scaler, the Input selection buttons light amber, green, and then
red before illuminating just the selected input.
Input Selection
Press any of the Input selection buttons on the front panel to select an input. The current
active input lights as follows:
Input Selection Button Lights
Color Signal
Amber Audio and video
Green Video only
Red Audio only
On-Screen Display (OSD) Menu System
The OSD menu is used primarily when the scaler is initially set up, but configuration and
adjustments can also be performed with Extron Simple Instruction Set (SIS) commands
(see
SIS Configuration and Control on page 31), the Product Configuration Software
(see Configuration Software on page 54), or the internal Web pages (see Internal Web
Pages on page 60). The OSD menu presents configuration options on a local monitor and
can be adjusted with front panel controls.
NOTE: The OSD menu has a fixed time-out of 60 seconds.
Menu Navigation Using Front Panel Controls
Menu button — Press the Menu button to activate or exit the OSD menu, unselect a
submenu, or cancel a pending change.
Enter button — Press the Enter button to activate the OSD menu, select submenus or
submenu items, or accept pending changes.
Navigation buttons — Press the Up ( > ) button or the Down ( < ) button to navigate
submenus or submenu items. Press the Right (
>
) button to access currently selected
submenus or submenu items. Press the Left ( > ) button to exit currently selected submenus
or submenu items. Also use the navigation buttons to adjust settings according to specific
setting directions.
Input selection buttons — Press any of the Input selection buttons to change the
selected input.
