IN1606 and IN1608 Series Scaling Presentation Switcher • SIS Configuration and Control
41
Command
ASCII Command
(host to scaler)
Response
(scaler to host)
Additional Description
Pixel phase (available only for RGB and YUV-HD input signals)
Specify a value
EX%
PHAS
}
Phas
X!
*
X%]
Set the pixel phase to
X%
on the current
input.
Increment value
E
+PHAS
}
Phas
X!
*
X%]
Increase the pixel phase on the current input.
Decrement value
E
-PHAS
}
Phas
X!
*
X%]
Decrease the pixel phase on the current
input.
View
E
PHAS
}
X%]
View the pixel phase setting on the current
input.
Total pixels (available only for RGB and YUV-HD input signals)
Specify a value
EX^
TPIX
}
Tpix
X!
*
X^]
Set the total pixels to
X^
on the current input.
Increment value
E
+TPIX
}
Tpix
X!
*
X^]
Increase the total pixels on the current input.
Decrement value
E
-TPIX
}
Tpix
X!
*
X^]
Decrease the total pixels on the current input.
View
E
TPIX
}
X^]
View the total pixel setting on the current
input.
Active pixels
Specify a value
EX&
APIX
}
Apix
X!
*
X&]
Set the active pixels to
X&
on the current
input.
Increment value
E
+APIX
}
Apix
X!
*
X&]
Increase the active pixels on the current
input.
Decrement value
E
-APIX
}
Apix
X!
*
X&]
Decrease the active pixels on the current
input.
View
E
APIX
}
X&]
View the active pixel setting on the current
input.
Active lines
Specify a value
EX*
ALIN
}
Alin
X!
*
X*]
Set the active lines to
X*
on the current
input.
Increment value
E
+ALIN
}
Alin
X!
*
X*]
Increase the active lines on the current input.
Decrement value
E
-ALIN
}
Alin
X!
*
X*]
Decrease the active lines on the current
input.
View
E
ALIN
}
X*]
View the active lines setting on the current
input.
3:2, 2:2, 24:1 Film mode detect
Auto
EX!
*1FILM
}
Film
X!
*
X1@]
Set film mode detection to automatic
(default).
Off
EX!
*0FILM
}
Film
X!
*
X1@]
Disable film mode detection.
View setting
EX!
FILM
}
X1@]
View the current film mode setting.
NOTES:
X!
= Input selection
1-6
(IN1606) or
1-8
(IN1608 models)
X%
= Pixel phase
0-63
(
31
= default)
X^
= Total pixels
±
512
of the default value
X&
= Active pixels
±
512
of the default value
X*
= Active lines
±
256
of the default value
X1@
= Film detect mode
0
= disabled
1
= auto (default)
