Example:

-> GOESSTBUFFERCOUNT?

5

Command sent to the XL™.

GOES ST Buffer Count = 512

rs

Response from XL™.

Command:

GOESSTCOLUMNnSOURCE?

Description:

Read the source of the n

th

column of data to be sent in the GOES self timed

transmission.

Parameters:

‘n’ can range from 1-20, indicating the corresponding column.

Response:

The source of the column corresponding to ‘n’ (e.g. Stage, PSI, Temp).

Example:

-> GOESSTCOLUMN2SOURCE?

5

Command sent to
XL™.

GOES ST Column 2 Source = Date

rs

Response from XL™.

Command:

GOESSTCOLUMNnSOURCE=XXXXXX

Description:

Set the source of the n

th

data column of the self timed GOES transmission.

Parameters:

‘n’ ranges from 1-20. The XL™ expects the new source of the data column
corresponding to ‘n’ (e.g. Stage, PSI, Temp).

Response:

None.

Example:

-> GOESSTCOLUMN15SOURCE=Temp

5

Command sent to the XL™.

rs

Response from the XL™.

Command:

GOESSTCOLUMNnSHEFCODE?

Description:

Read the SHEF code of the n

th

column of data to sent in the GOES self timed

transmission. The SHEF code is included as a description of the value. The SHEF
code pneumonics are pre-defined. (See GOES section for details)

Parameters:

‘n’ can range from 1-20.

Response:

The response is an ASCII text string with the SHEF code for the n

th

column.

Example:

-> GOESSTCOLUMN1SHEFCODE?

5

Command.

GOES ST Column 1 SHEF Code = SH

rs

Response.

H-5223

Remote Operation (Command Mode) C-39
