2.3 Top Panel Description
On the top of the H-5223 are antenna connectors, power connectors, host and auxiliary
connectors, GOES fail safe button, and LED indicators
2.3.1 GOES Antenna
This is the GOES RF antenna connector and is a male SMA type of connector. Most GOES RF
antenna cables have an N type of connector so an adaptor will be needed to go from the one
connector type to the other.
2.3.2 +12VDC / Ground
This is the primary power connection to supply power to the transmitter.
2.3.3 Fail Safe Button
This button is used to manually reset the failsafe when it is tripped. The button needs to be
pressed and held in for 3 seconds to reset the failsafe.
2.3.4 LED indicators
Failsafe: Blinks to indicate that the failsafe has been tripped.
RF On (Solid): When LED is continuously on this indicates that a transmission is in
progress.
RF On (Blinking): When LED is blinking this indicates the transmitter failsafe timer is
running.
GPS On (Solid): When this LED is continuously on this indicates that the GPS receiver is
fixed onto 3 or more satellites.
GPS On (Blinking): When LED is blinking this indicates that the GPS is trying to acquire a
GPS fix.
2.3.5 GPS Antenna
This is the GPS antenna connector. The GPS antenna should be mounted in clear view of the
sky.
H-5223
Hardware Options and Installation 2-7
