or for on at scan, pressing the 1 key will cause the output to toggle between high and low. If
the pin is configured as an input of any type the message ‘NA’ will be displayed.

N - Next
This option is used to move to digital I/O number 2.

NOTE:

Digital I/O 2 is configured the same as digital I/O 1 so no further discussion is
given for the second digital I/O pin.

H-5223

Remote Operation (Menu Mode) 3-9
