TECHNOFORCE Installation, Operation, and Maintenance 66
Appendix
NPT NPA Point Description Range/Value Units
BI 35 Analog Input #3 Failure 1 = Failure 0 = O.K.
BI 36 Analog Input #4 Failure 1 = Failure 0 = O.K.
BI 37 General Alarm 1 = Alarm 0 = O.K.
BI 38 System Operation Mode 1 = Auto 0 = Manual
BO 1 Pump Sequence Alternation 1 = Yes 0 = No
BO 2 System Reset Request 1 = Yes 0 = No
BO 3 System Start / Stop 1 = Start 0 = Stop
ADI 1 System Pressure 0 to Span (in TechnoForce User Setup Menu) PSI
ADI 2 Suction Pressure 0 to Span (in TechnoForce User Setup Menu) PSI
ADI 3 AI #1 0 to Span (in TechnoForce User Setup Menu)
ADI 4 AI #2 0 to Span (in TechnoForce User Setup Menu)
ADI 5 AI #3 0 to Span (in TechnoForce User Setup Menu)
ADI 6 AI #4 0 to Span (in TechnoForce User Setup Menu)
ADI 7 Setpoint #1 0 to Span (in TechnoForce User Setup Menu)
ADI 8 Setpoint #2 0 to Span (in TechnoForce User Setup Menu)
ADI 9 Setpoint #3 0 to Span (in TechnoForce User Setup Menu)
ADI 10 Setpoint #4 0 to Span (in TechnoForce User Setup Menu)
ADI 11 System Flow 0 to Span (in TechnoForce User Setup Menu) GPM
ADI 12 System Power (KW) 0 to Span (in TechnoForce User Setup Menu) KW
ADI 13 Drive #1 Current 0 to Span (in TechnoForce User Setup Menu) A
ADI 14 Drive #2 Current 0 to Span (in TechnoForce User Setup Menu) A
ADI 15 Drive #3 Current 0 to Span (in TechnoForce User Setup Menu) A
ADI 16 Drive #4 Current 0 to Span (in TechnoForce User Setup Menu) A
ADI 17 Drive #5 Current 0 to Span (in TechnoForce User Setup Menu) A
ADI 18 Drive #6 Current 0 to Span (in TechnoForce User Setup Menu) A
ADI 19 Drive #1 Power (KW) 0 to Span (in TechnoForce User Setup Menu) KW
ADI 20 Drive #2 Power (KW) 0 to Span (in TechnoForce User Setup Menu) KW
ADI 21 Drive #3 Power (KW) 0 to Span (in TechnoForce User Setup Menu) KW
ADI 22 Drive #4 Power (KW) 0 to Span (in TechnoForce User Setup Menu) KW
ADI 23 Drive #5 Power (KW) 0 to Span (in TechnoForce User Setup Menu) KW
ADI 24 Drive #6 Power (KW) 0 to Span (in TechnoForce User Setup Menu) KW
ADI 25 Speed % 0 to 100 %
ADI 26 Lead Pump Number 1 to Pump # (in TechnoForce User Setup Menu)
ADI 27 Active Zone Number 1 to Zone # (in TechnoForce User Setup Menu)
