TECHNOFORCE Installation, Operation, and Maintenance 25
Installation
Password Menu Items (continued)
Menu Item Variable Default Range Field
Value
Verify VERIFY THE PASSWORD
PASSWD >_ _ _ _ _ _<
After entering data in password definition screen this
screen requires the user to confirm the requested
password. If the confirmed number does not agree with
the first number the Enter New Password screen is
repeated to allow the user to get both input screens
to agree.
4.10.17 I/O setup menu
Paths: Status Screens / Set up(3) / System(3) / IO Setup(9)
See the following table for all
I/O Setup menu items.
NOTE: The total available number of I/O to be configured depends on the system setup. Complete all previous
setup screens, specifically pumps and sensors prior to completing the following.
I/O Setup Menu Items
Menu Item Variable Default Range Field
Value
DI Opt. DI #### N/A 0-999
Enter the input to be configured as it appears on the
terminal number.
Avail: ## N/A 0-99
This screen can not be modified. It is here to advise the
user of how many digital inputs can be customized
* Code: ### 0 0-255
Enter the code to define the desired functionality of the
input. Valid codes are defined in the Appendix of this
manual.
DO Total Avail. DO = # N/A 0-99
This screen can not be modified. It is here to advise the
user of how many digital outputs can be customized
* DO No: #### N/A 0-999
Enter the output to be configured as it appears on the
terminal number.
* Code: ### 0 0-255
Enter the code to define the desired functionality of the
output. Valid codes are defined in the Appendix of this
manual.
AO Total Avail. AO = # N/A 0-99
This screen can not be modified. It is here to advise the
user of how many analog outputs can be customized
* Code: ### 0 0-255
Enter the code to define the desired functionality of the
output. Valid codes are defined in the Appendix of
this manual.
NOTE: If a programming error happens, an error message is displayed. An error may be due to reprogramming
an input that is currently used by the system or inputting an undefined code number.
