TECHNOFORCE Installation, Operation, and Maintenance
13
Installation
4.7.2 Table 1 Key Functionality
Key Name
Functionality
START/STOP
Starts or stops the system.
AUTO/ MANUAL
Toggles the operation mode. The system must be stopped to change the
operation mode.
PUMP 1-6 ENABLE Enables or disables the corresponding pump. Pumps cannot be disabled
while they are failed.
RESET/ SILENCE
This key is used to reset alarms and events. When the A/V Alarm relay
output is set. Pressing of this key resets the alarms and events.
HELP
Press the HELP button, from the status screens, to view alarms or events
while the HELP LED is flashing. While in the Alarm screen, press the HELP
button again to view help messages for active alarms. Press HELP any other
time to view screen specific help messages.
PV/1
Press PV from the status screens, to bring up the process variable screen
SETPT/2
Press SET PT from the status screens, to bring up the set point menu shown in
section 5.5
SETUP/3
Press SETUP, from the status screens, to bring up the Setup Menu shown in
section 4.10
ALT/4
Press ALT, from the status screens, to manually alternate the pump staging
sequence.
LOG/5
Press LOG, from the status screens, to bring up the Log Menu, shown in
section 6.14.0
YES/7
Press YES at OK prompts to accept values and proceed
INFO/8
Press INFO, from the status screens, to bring up the program type and version
number shown in section 6.14
NO/0
Press NO at OK prompts to edit the parameters
ENTER
Confirms entries
CLEAR
Clears entries or used to exit some screens
PREV/( )
Navigates to neighboring screens
NEXT/( )
Navigates to neighboring screens
UP (▲)
Used to modify values and navigate to neighboring screens
DOWN (▼)
Used to modify values and navigate to neighboring screens
Note: Setting the display contrast.
The Contrast on the display is set at the factory. However, the user can make a different
contrast setting as desired. To do this press “Enter”. while holding down this key, the “UP” and
“DOWN” key can be used to set contrast.
ENTER + UP... increase contrast
ENTER + DOWN... reduce contrast
▲
▲
