TECHNOFORCE Installation, Operation, and Maintenance
64
Appendix
TechnoForce MODBUS Communication Points (continued)
Function Points # Point
Range/
Modbus Units
Code
Description
Value
Address
04
1
System Pressure
0 to Span (in TechnoForce
30001
PSI
User Setup Menu)
04
2
Suction Pressure
0 to Span (in TechnoForce
User Setup Menu)
30002
PSI
04, 06
3
AI #1
0 to Span (in TechnoForce
30003,
User Setup Menu)
40003
04, 06
4
AI #2
0 to Span (in TechnoForce
30004,
User Setup Menu)
40004
04, 06
5
AI #3
0 to Span (in TechnoForce
30005,
User Setup Menu)
40005
04, 06
6
AI #4
0 to Span (in TechnoForce
30006,
User Setup Menu)
40006
04, 06
7
Setpoint #1
0 to Span (in TechnoForce
30007,
User Setup Menu)
40007
04, 06
8
Setpoint #2
0 to Span (in TechnoForce
30008,
User Setup Menu)
40008
04, 06
9
Setpoint #3
0 to Span (in TechnoForce
30009,
User Setup Menu)
40009
04, 06
10
Setpoint #4
0 to Span (in TechnoForce
30010,
User Setup Menu)
40010
04
11
System Flow
0 to Span (in TechnoForce
User Setup Menu)
30011
GPM
04
12
System Power (KW)
0 to Span (in TechnoForce
User Setup Menu)
30012
KW
04
13
Drive #1 Current
0 to Span (in TechnoForce
User Setup Menu)
30013
A
04
14
Drive #2 Current
0 to Span (in TechnoForce
User Setup Menu)
30014
A
04
15
Drive #3 Current
0 to Span (in TechnoForce
User Setup Menu)
30015
A
04
16
Drive #4 Current
0 to Span (in TechnoForce
User Setup Menu)
30016
A
04
17
Drive #5 Current
0 to Span (in TechnoForce
User Setup Menu)
30017
A
04
18
Drive #6 Current
0 to Span (in TechnoForce
User Setup Menu)
30018
A
04
19
Drive #1 Power (KW)
0 to Span (in TechnoForce
User Setup Menu)
30019
KW
04
20
Drive #2 Power (KW)
0 to Span (in TechnoForce
User Setup Menu)
30020
KW
04
21
Drive #3 Power (KW)
0 to Span (in TechnoForce
User Setup Menu)
30021
KW
04
22
Drive #4 Power (KW)
0 to Span (in TechnoForce
User Setup Menu)
30022
KW
04
23
Drive #5 Power (KW)
0 to Span (in TechnoForce
User Setup Menu)
30023
KW
04
24
Drive #6 Power (KW)
0 to Span (in TechnoForce
User Setup Menu)
30024
KW
