TECHNOFORCE Installation, Operation, and Maintenance

62

Appendix

Object Identifier

Object Name

Range

Analog Input, 1

System Pressure

0 to Span (in TechnoForce User Setup Menu)

Analog Input, 2

Suction Pressure

0 to Span (in TechnoForce User Setup Menu)

Analog Input, 3

AI #1

0 to Span (in TechnoForce User Setup Menu)

Analog Input, 4

AI #2

0 to Span (in TechnoForce User Setup Menu)

Analog Input, 5

AI #3

0 to Span (in TechnoForce User Setup Menu)

Analog Input, 6

AI #4

0 to Span (in TechnoForce User Setup Menu)

Analog Input, 7

Setpoint #1

0 to Span (in TechnoForce User Setup Menu)

Analog Input, 8

Setpoint #2

0 to Span (in TechnoForce User Setup Menu)

Analog Input, 9

Setpoint #3

0 to Span (in TechnoForce User Setup Menu)

Analog Input, 10

Setpoint #4

0 to Span (in TechnoForce User Setup Menu)

Analog Input, 11

System Flow

0 to Span (in TechnoForce User Setup Menu)

Analog Input, 12

System Power (KW)

0 to Span (in TechnoForce User Setup Menu)

Analog Input, 13

Drive #1 Current

0 to Span (in TechnoForce User Setup Menu)

Analog Input, 14

Drive #2 Current

0 to Span (in TechnoForce User Setup Menu)

Analog Input, 15

Drive #3 Current

0 to Span (in TechnoForce User Setup Menu)

Analog Input, 16

Drive #4 Current

0 to Span (in TechnoForce User Setup Menu)

Analog Input, 17

Drive #5 Current

0 to Span (in TechnoForce User Setup Menu)

Analog Input, 18

Drive #6 Current

0 to Span (in TechnoForce User Setup Menu)

Analog Input, 19

Drive #1 Power (KW)

0 to Span (in TechnoForce User Setup Menu)

Analog Input, 20

Drive #2 Power (KW)

0 to Span (in TechnoForce User Setup Menu)

Analog Input, 21

Drive #3 Power (KW)

0 to Span (in TechnoForce User Setup Menu)

Analog Input, 22

Drive #4 Power (KW)

0 to Span (in TechnoForce User Setup Menu)

Analog Input, 23

Drive #5 Power (KW)

0 to Span (in TechnoForce User Setup Menu)

Analog Input, 24

Drive #6 Power (KW)

0 to Span (in TechnoForce User Setup Menu)

Analog Input, 25

Speed %

0 to 100

Analog Input, 26

Lead Pump Number

1 to Pump # (in TechnoForce User Setup Menu)

Analog Input, 27

Active Zone Number

1 to Zone # (in TechnoForce User Setup Menu)

Analog Output, 1

AI1_Command

0-65535

Analog Output, 2

AI2_Command

0-65535

Analog Output, 3

AI3_Command

0-65535

Analog Output, 4

AI4_Command

0-65535

Analog Output, 5

SP1_Command

0-65535

Analog Output, 6

SP2_Command

0-65535

Analog Output, 7

SP3_Command

0-65535

Analog Output, 8

SP4_Command

0-65535
