TECHNOFORCE Installation, Operation, and Maintenance 20
Use the appropriate numeric key to select the desired menu, then press the ENTER key. See the following table
for all VFD menu items.
VFD Menu Items
Menu Item Variable Default Range Field
Value
VFD Setup Accel Tm: ## 5 0-1800
Drive acceleration time in seconds from zero to
maximum frequency ramp
Decel Tm: ## 5 0-1800
Drive acceleration time in seconds from maximum to
zero to maximum frequency ramp
Freq Max : ## 60 0-60
Enter the maximum limit for the drive output frequency
Freq Min : 30
Enter the minimum limit for the drive output frequency
VFD Set VFD: # 0 0-65,
Parameter The VFD number in which the parameter needs to be set. 535
ADDRESS:
Enter the parameter code from the parameter list
available in the ABB user’s manual supplied.
RESOLUTION: #
Enter the value of parameter “Resolution” from the
parameter list available in the ABB user’s
manual supplied.
VALUE:
Enter the desired parameter value.
VFD Read VFD: # 0 0-65,
Parameter The VFD number from which the parameter needs
535
to be read.
ADDRESS:
Enter the parameter code from the parameter list
available in the ABB user’s manual supplied.
RESOLUTION: #
Enter the resolution from the parameter list available
in the ABB user’s manual supplied.
OFFSET:
Enter the lower limit of the parameter “Range” from
the parameter list available in the ABB user’s
manual supplied.
READ:
Press YES/7 key and ENTER key to read the
parameter values
All Sys Sen PUMP SPEED: 100 0-100
Fail Enter the % speed for the drive(s) to operate at in the
event that all system sensor fail.
NO OF PUMP RUN: 1 1-6
Enter the number of pumps that should operate at the
above speed in the event that all system sensor fail.
