TECHNOFORCE Installation, Operation, and Maintenance 61
Appendix
7.3 TechnoForce BACnet Communication Objects List for Application
Version 1.16 or Above
Object Identifier Object Name Range
Binary Input, 1 P1 Failure 1 = Failure 0 = O.K.
Binary Input, 2 P1 VFD Failure 1 = Failure 0 = O.K.
Binary Input, 3 P1 Off 1 = Alarm 0 = O.K.
Binary Input, 4 P2 Failure 1 = Failure 0 = O.K.
Binary Input, 5 P2 VFD Failure 1 = Failure 0 = O.K.
Binary Input, 6 P2 Off 1 = Alarm 0 = O.K.
Binary Input, 7 P3 Failure 1 = Failure 0 = O.K.
Binary Input, 8 P3 VFD Failure 1 = Failure 0 = O.K.
Binary Input, 9 P3 Off 1 = Alarm 0 = O.K.
Binary Input, 10 P4 Failure 1 = Failure 0 = O.K.
Binary Input, 11 P4 VFD Failure 1 = Failure 0 = O.K.
Binary Input, 12 P4 Off 1 = Alarm 0 = O.K.
Binary Input, 13 P5 Failure 1 = Failure 0 = O.K.
Binary Input, 14 P5 VFD Failure 1 = Failure 0 = O.K.
Binary Input, 15 P5 Off 1 = Alarm 0 = O.K.
Binary Input, 16 P6 Failure 1 = Failure 0 = O.K.
Binary Input, 17 P6 VFD Failure 1 = Failure 0 = O.K.
Binary Input, 18 P6 Off 1 = Alarm 0 = O.K.
Binary Input, 19 System Reset Req 1 = Yes 0 = No
Binary Input, 20 P1 Enabled 1 = Enabled 0 = Disabled
Binary Input, 21 P2 Enabled 1 = Enabled 0 = Disabled
Binary Input, 22 P3 Enabled 1 = Enabled 0 = Disabled
Binary Input, 23 P4 Enabled 1 = Enabled 0 = Disabled
Binary Input, 24 P5 Enabled 1 = Enabled 0 = Disabled
Binary Input, 25 P6 Enabled 1 = Enabled 0 = Disabled
Binary Input, 26 Pump #1 On/Off 1 = On 0 = Off
Binary Input, 27 Pump #2 On/Off 1 = On 0 = Off
Binary Input, 28 Pump #3 On/Off 1 = On 0 = Off
Binary Input, 29 Pump #4 On/Off 1 = On 0 = Off
Binary Input, 30 Pump #5 On/Off 1 = On 0 = Off
Binary Input, 31 Pump #6 On/Off 1 = On 0 = Off
Binary Input, 32 System Start/Stop 1 = Start 0 = Stop
Binary Input, 33 AI #1 Failure 1 = Failure 0 = O.K.
Binary Input, 34 AI #2 Failure 1 = Failure 0 = O.K.
Binary Input, 35 AI #3 Failure 1 = Failure 0 = O.K.
Binary Input, 36 AI #4 Failure 1 = Failure 0 = O.K.
Binary Input, 37 General Alarm 1 = Alarm 0 = O.K.
Binary Input, 38 System Operation Mode 1 = Auto 0 = Manual
Binary Output, 1 Pump Sequence Alternation 1 = Yes 0 = No
Binary Output, 2 System Reset Request 1 = Yes 0 = No
Binary Output, 3 System Start / Stop 1 = Start 0 = Stop
